Wholesale Semi Electric Stacker-CDD10B-III Suppliers, OEM/ODM Company

Productum

Semi Electric Stacker-CDD10B-III

Model

CDD10B-III

Semi-electrica Stacker

Catena manubrium catenae adiuvat, ratio gubernandi laborem vehementer minuit intensionem.
valvae explosione-probationis instructus, contra subitam fuscinulam guttam et ne operator ab iniuria fiat.
Nimia tutelae fabrica artificium nimis prorogat tempus autonomiae vitae.
Altiore genus aptabile fuscinularum, quae eodem crurum gradu demitti possunt.
Catena ad latus rotae et manubrium applicans, ad gubernandum facilis.
Securus pes operating fregit.

Contactus nunc

Quaeritur quaestio

PREV：Plena Electric Stacker-CDD10R-E

NEXT：Semi Electric Stacker-EJ

Product Description

Model		CDD10B -III (Super tridentes)	CDD15B -III (Super tridentes)
Facultatem onus	Q(kg)	1000	1500
Onus centrum spatium	c(mm)	500	500
Lond procul, centrum coegi axem ad furca	x (mm)	802	802
Tyrus magnitudine, fronte	mm	φ180x50	φ180x50
Tyrus magnitudine, tergo	mm	φ80x77	φ80x77
Rotae numero ancipiti (x rotis agitatae)		2/2	2/2
Furca altitudo, demissa	h13(mm)	90
Altitudo, malum demissum	h1 (mm)	2090/1840/2090/2240/2340
Maximilianus. altitudo levare	h3 (mm)	1600/2500/3000/3300/3500
Altitudo, malum extensum	h4(mm)	2090/3060/3560/3860/4060
Longitudo altiore	l1 (mm)	1678	1740
Longitudo ad faciem fuscinulas	l2(mm)	608	670
Altiore latitudine	b1 (mm)	800	800
Furca dimensiones	s/e/l(mm)	60/170/1070	60/170/1070
Latitudo altiore tridentes	b5(mm)	570/695	570/695
Aisle latitudinem longitudinum 800x1200 cursare	Ast (mm)	2267	2347
Conversus radii	WA (mm)	1425	1505
Celeritas levare, onustus/exonerare	m/s****	0.07/0.10	0.07/0.10(0.06/0.10)
Celeritas demissio, onustus/exoneratus	m/s	0.15/0.12	0.12/0.15(0.15/0.12)
Servitium fregit		mechanica	mechanica
Pugna voltage, capacitas nominalis K5	V/Ah	12/120	24/120(12/120)
altilium pondus	kg	45	45
Pugna dimensiones l / w / h *	mm	360x170x250	360x170x250
Officium pondus (cum altilium)	kg	355/410/445/475/495	405/475/480/530/550

Model		CDD10B-III (Adjustable tridentes)	CDD15B-III (Adjustable tridentes)
Facultatem onus	Q(kg)	1000	1500
Onus centrum spatium	c(mm)	500	500
Lond procul, centrum coegi axem ad furca	x (mm)	745	745
Tyrus magnitudine, fronte	mm	φ180x50	φ180x50
Tyrus magnitudine, tergo	mm	φ80x77	φ80x77
Rotae numero ancipiti (x rotis agitatae)		2/2	2/2
Furca altitudo, demissa	h13(mm)	90
Altitudo, malum demissum	h1 (mm)	2090/1840/2090/2240/2340
Maximilianus. altitudo levare	h3 (mm)	1600/2500/3000/3300/3500
Altitudo, malum extensum	h4(mm)	2090/3060/3560/3860/4060
Longitudo altiore	l1 (mm)	1735	1835
Longitudo ad faciem fuscinulas	l2(mm)	665	765
Altiore latitudine	b1 (mm)	800	800
Furca dimensiones	s/e/l(mm)	60/142/1070	60/142/1070
Latitudo altiore tridentes	b5(mm)	295-930	295-930
Aisle latitudinem longitudinum 800x1200 cursare	Ast (mm)	2267	2347
Conversus radii	WA (mm)	1425	1505
Celeritas vitae, onusta/exonerata	m/s	0.07/0.10	0.07/0.10(0.06/0.10)
Celeritas demissio, onustus/exoneratus	m/s	0.15/0.12	0.12/0.15(0.15/0.12)
Servitium fregit		mechanica	mechanica
Pugna voltage, capacitas nominalis K5	V/Ah	12/120	24/120(12/120)
altilium pondus	kg	45	45
Pugna dimensiones l / w / h *	mm	360x170x250	360x170x250
Officium pondus (cum altilium)	kg	385/440/475/505/525	435/510/535/560/580
